APTGF90A60T1G
RoHS
/
Package SP1
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
POWER MOD IGBT NPT PHASE LEG SP1
PDF
/
Inventory: 9056
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Pbfree Code yes
JESD-609 Code e1
VCEsat-Max 2.5 V
Input Capacitance (Cies) @ Vce 4.3nF @ 25V
Gate-Emitter Voltage-Max 20V
NTC Thermistor Yes
IGBT Type NPT
Turn Off Time-Nom (toff) 210 ns
Vce(on) (Max) @ Vge, Ic 2.5V @ 15V, 90A
Turn On Time 51 ns
Input Capacitance 4.3nF
Collector Emitter Breakdown Voltage 600V
Current - Collector Cutoff (Max) 250μA
Max Collector Current 110A
Collector Emitter Voltage (VCEO) 600V
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Case Connection ISOLATED
Element Configuration Dual
Configuration Half Bridge
Number of Elements 2
Pin Count 12
Terminal Form THROUGH-HOLE
Terminal Position UPPER
Max Power Dissipation 416W
Subcategory Insulated Gate BIP Transistors
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish TIN SILVER COPPER
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Physical
Number of Pins 12
Package / Case SP1
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
