APT30GP60JDQ1
RoHS
RoHS compliant
RoHS compliantPackage SOT-227-4, miniBLOC
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MODULE 600V 67A 245W ISOTOP
PDF
/
Inventory: 5419
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case SOT-227-4, miniBLOC
Number of Pins 4
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Published 1999
Series POWER MOS 7?
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Additional Feature LOW CONDUCTION LOSS
Voltage - Rated DC 600V
Max Power Dissipation 245W
Terminal Position UPPER
Terminal Form UNSPECIFIED
Current Rating 63A
Pin Count 4
Number of Elements 1
Configuration Single
Case Connection ISOLATED
Power - Max 245W
Transistor Application POWER CONTROL
Polarity/Channel Type N-CHANNEL
Input Standard
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 67A
Current - Collector Cutoff (Max) 500μA
Collector Emitter Breakdown Voltage 600V
Input Capacitance 3.2nF
Turn On Time 31 ns
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 30A
Turn Off Time-Nom (toff) 165 ns
IGBT Type PT
NTC Thermistor No
Input Capacitance (Cies) @ Vce 3.2nF @ 25V
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
