MG12300D-BN2MM
RoHS
RoHS compliant
RoHS compliantPackage D-3 Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT Modules 1200V 300A Dual 150TVj
PDF
/
Buying Options
Total Price: USD $176.59
Unit Price: USD $176.5896
≥1 USD $176.5896
Inventory: 52
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Package / Case D-3 Module
Number of Pins 7
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2013
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Power Dissipation 1.45kW
Polarity NPN
Configuration Half Bridge
Element Configuration Dual
Power Dissipation 1.45kW
Power - Max 1450W
Input Standard
Collector Emitter Voltage (VCEO) 1.2kV
Max Collector Current 480A
Current - Collector Cutoff (Max) 1mA
Collector Emitter Breakdown Voltage 1.2kV
Voltage - Collector Emitter Breakdown (Max) 1200V
Collector Emitter Saturation Voltage 1.7V
Input Capacitance 21nF
Vce(on) (Max) @ Vge, Ic 1.7V @ 15V, 300A
NTC Thermistor No
Input Capacitance (Cies) @ Vce 21nF @ 25V
Dimensions
Height 30.5mm
Length 108mm
Width 62mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
