VKI50-12P1
RoHS
/
Package ECO-PAC2
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
Trans IGBT Module N-CH 1.2KV 49A 11-Pin ECO-PAC 2
PDF
/
Buying Options
Total Price: USD $215
Unit Price: USD $215
≥1 USD $215
≥10 USD $208.83019
≥100 USD $200.34923
Inventory: 964
Minimum: 1
-
+
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case ECO-PAC2
Number of Pins 11
Technical
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Max Power Dissipation 208W
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
JESD-30 Code R-XUFM-X16
Qualification Status Not Qualified
Number of Elements 4
Configuration Full Bridge Inverter
Case Connection ISOLATED
Transistor Application MOTOR CONTROL
Polarity/Channel Type N-CHANNEL
Input Standard
Collector Emitter Voltage (VCEO) 3.7V
Max Collector Current 49A
Current - Collector Cutoff (Max) 1.1mA
Collector Emitter Breakdown Voltage 1.2kV
Voltage - Collector Emitter Breakdown (Max) 1200V
Input Capacitance 1.65nF
Turn On Time 170 ns
Vce(on) (Max) @ Vge, Ic 3.7V @ 15V, 50A
Turn Off Time-Nom (toff) 570 ns
IGBT Type NPT
NTC Thermistor Yes
Input Capacitance (Cies) @ Vce 1.65nF @ 25V
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
