VKI50-06P1
RoHS
RoHS compliant
RoHS compliantPackage ECO-PAC2
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
MOD IGBT H-BRIDGE 600V ECO-PAC2
PDF
/
Inventory: 1785
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Input Capacitance (Cies) @ Vce 16nF @ 25V
NTC Thermistor Yes
IGBT Type NPT
Turn Off Time-Nom (toff) 310 ns
Vce(on) (Max) @ Vge, Ic 2.9V @ 15V, 50A
Turn On Time 100 ns
Input Capacitance 16nF
Collector Emitter Breakdown Voltage 600V
Current - Collector Cutoff (Max) 600μA
Max Collector Current 42.5A
Collector Emitter Voltage (VCEO) 2.9V
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Power - Max 130W
Case Connection ISOLATED
Configuration Full Bridge Inverter
Number of Elements 4
Qualification Status Not Qualified
JESD-30 Code R-XUFM-X16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Max Power Dissipation 130W
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2002
Operating Temperature -40°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 11
Package / Case ECO-PAC2
Mounting Type Chassis Mount
Mount Chassis Mount
