MUBW15-06A6
RoHS
/
Package E1
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MODULE 600V 18A 61W E1
PDF
/
Inventory: 7093
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Input Capacitance (Cies) @ Vce 0.57nF @ 25V
Gate-Emitter Voltage-Max 20V
NTC Thermistor Yes
IGBT Type NPT
Turn Off Time-Nom (toff) 325 ns
Vce(on) (Max) @ Vge, Ic 2.5V @ 15V, 10A
Turn On Time 80 ns
Input Capacitance 570pF
Collector Emitter Breakdown Voltage 600V
Current - Collector Cutoff (Max) 1mA
Max Collector Current 18A
Collector Emitter Voltage (VCEO) 2.5V
Input Three Phase Bridge Rectifier
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 61W
Case Connection ISOLATED
Configuration Three Phase Inverter with Brake
Number of Elements 7
Qualification Status Not Qualified
Pin Count 25
Base Part Number MUBW
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Max Power Dissipation 61W
Subcategory Insulated Gate BIP Transistors
Additional Feature FAST
Terminal Finish Matte Tin (Sn)
Number of Terminations 25
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2000
Operating Temperature -40°C~125°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 25
Package / Case E1
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
