MUBW10-12A7
RoHS
RoHS compliant
RoHS compliantPackage E2
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
Trans IGBT Module N-CH 1.2KV 20A 24-Pin E2-Pack
PDF
/
Buying Options
Total Price: USD $160.24
Unit Price: USD $160.242071
≥1 USD $160.242071
≥198 USD $63.93823
≥498 USD $61.802142
≥1002 USD $60.74657
Inventory: 5768
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Technical
Input Capacitance (Cies) @ Vce 0.6nF @ 25V
NTC Thermistor Yes
IGBT Type NPT
Turn Off Time-Nom (toff) 350 ns
Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 10A
Turn On Time 90 ns
Input Capacitance 600pF
Reverse Voltage 1.6kV
Voltage - Collector Emitter Breakdown (Max) 1200V
Collector Emitter Breakdown Voltage 1.2kV
Current - Collector Cutoff (Max) 600μA
Max Collector Current 20A
Collector Emitter Voltage (VCEO) 2.7V
Input Three Phase Bridge Rectifier
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 105W
Case Connection ISOLATED
Configuration Three Phase Inverter with Brake
Number of Elements 7
Qualification Status Not Qualified
Base Part Number MUBW
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 19A
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Max Power Dissipation 105W
Voltage - Rated DC 1.6kV
Additional Feature LOW SWITCHING LOSS, LOW SATURATION VOLTAGE
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Number of Terminations 24
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2001
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 2
Package / Case E2
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 20 Weeks
Alternative Model
