MIXA10W1200TML
RoHS
RoHS compliant
RoHS compliantPackage E1
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT Modules Six Pack XPT IGBT
PDF
/
Inventory: 1424
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Gate-Emitter Voltage-Max 20V
NTC Thermistor Yes
IGBT Type PT
Turn Off Time-Nom (toff) 350 ns
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 9A
Turn On Time 110 ns
Voltage - Collector Emitter Breakdown (Max) 1200V
Collector Emitter Breakdown Voltage 1.2kV
Current - Collector Cutoff (Max) 150μA
Max Collector Current 17A
Collector Emitter Voltage (VCEO) 2.1V
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 65W
Case Connection ISOLATED
Configuration Three Phase Inverter
Number of Elements 6
JESD-30 Code R-PUFM-X24
Terminal Form UNSPECIFIED
Terminal Position UPPER
Max Power Dissipation 65W
Subcategory Insulated Gate BIP Transistors
Additional Feature UL RECOGNIZED
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2011
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Transistor Element Material SILICON
Package / Case E1
Mounting Type Chassis Mount
Mount Chassis Mount
