MIAA10WE600TMH
RoHS
/
Package MiniPack2
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MOD 600V 18A 70W MINIPACK2
PDF
/
Inventory: 8540
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case MiniPack2
Number of Pins 2
Transistor Element Material SILICON
Technical
Operating Temperature -40°C~125°C TJ
Published 2007
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 22
Additional Feature FAST SWITCHING
Subcategory Insulated Gate BIP Transistors
Max Power Dissipation 70W
Terminal Position UPPER
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MIAA10W
Pin Count 22
Qualification Status Not Qualified
Number of Elements 7
Configuration Three Phase Inverter with Brake
Case Connection ISOLATED
Power - Max 70W
Transistor Application MOTOR CONTROL
Polarity/Channel Type N-CHANNEL
Input Single Phase Bridge Rectifier
Collector Emitter Voltage (VCEO) 2.6V
Max Collector Current 18A
Current - Collector Cutoff (Max) 600μA
Collector Emitter Breakdown Voltage 600V
Reverse Voltage 1.6kV
Input Capacitance 450pF
Turn On Time 60 ns
Vce(on) (Max) @ Vge, Ic 2.6V @ 15V, 10A
Turn Off Time-Nom (toff) 260 ns
IGBT Type NPT
NTC Thermistor Yes
Input Capacitance (Cies) @ Vce 0.45nF @ 25V
Compliance
RoHS Status RoHS Compliant
