IXGN72N60A3
RoHS
RoHS compliant
RoHS compliantPackage SOT-227-4, miniBLOC
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MOD 600V 160A 360W SOT227B
PDF
/
Inventory: 2988
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Input Capacitance (Cies) @ Vce 6.6nF @ 25V
NTC Thermistor No
IGBT Type PT
Turn Off Time-Nom (toff) 885 ns
Vce(on) (Max) @ Vge, Ic 1.35V @ 15V, 60A
Turn On Time 61 ns
Input Capacitance 6.6nF
Collector Emitter Saturation Voltage 1.35V
Collector Emitter Breakdown Voltage 600V
Current - Collector Cutoff (Max) 75μA
Max Collector Current 160A
Collector Emitter Voltage (VCEO) 600V
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Case Connection ISOLATED
Power Dissipation 360W
Configuration Single
Number of Elements 1
Pin Count 4
Base Part Number IXG*72N60
Terminal Form UNSPECIFIED
Terminal Position UPPER
Max Power Dissipation 360W
Additional Feature UL RECOGNIZED, LOW CONDUCTION LOSS
Terminal Finish Nickel (Ni)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series GenX3?
Published 2008
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 4
Package / Case SOT-227-4, miniBLOC
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 30 Weeks
