IRG7U100HF12A
RoHS
/
Package POWIR? 34 Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MOD 1200V 200A POWIR 34
PDF
/
Inventory: 6928
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case POWIR? 34 Module
Technical
Operating Temperature -40°C~150°C TJ
Published 2014
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Power Dissipation 580W
Configuration Half Bridge
Power - Max 580W
Input Standard
Collector Emitter Voltage (VCEO) 2V
Max Collector Current 200A
Current - Collector Cutoff (Max) 1mA
Collector Emitter Breakdown Voltage 1.2kV
Voltage - Collector Emitter Breakdown (Max) 1200V
Input Capacitance 10nF
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 100A
NTC Thermistor No
Input Capacitance (Cies) @ Vce 10nF @ 25V
Compliance
RoHS Status RoHS Compliant
