FS450R17OE4PBOSA1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
MOD IGBT MED PWR ECONOPP-2
PDF
/
Buying Options
Total Price: USD $624.93
Unit Price: USD $624.932
≥1 USD $624.932
≥10 USD $603.12853
Inventory: 18
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Input Capacitance (Cies) @ Vce 36nF @ 25V
NTC Thermistor Yes
IGBT Type Trench Field Stop
Turn Off Time-Nom (toff) 1100 ns
Vce(on) (Max) @ Vge, Ic 2.3V @ 15V, 450A
Turn On Time 310 ns
Current - Collector (Ic) (Max) 900A
Voltage - Collector Emitter Breakdown (Max) 1700V
Current - Collector Cutoff (Max) 3mA
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 20mW
Case Connection ISOLATED
Configuration Full Bridge
Number of Elements 6
JESD-30 Code R-XUFM-X29
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Additional Feature UL RECOGNIZED
ECCN Code EAR99
Number of Terminations 29
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series EconoPACK?+
Published 2002
Operating Temperature -40°C~150°C
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case Module
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 52 Weeks
