FS35R12KT3BOSA1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
MOD IGBT LOW PWR ECONO2-6
PDF
/
Buying Options
Total Price: USD $135.47
Unit Price: USD $135.472899
≥1 USD $135.472899
≥200 USD $52.426723
≥500 USD $50.583411
≥1000 USD $49.673572
Inventory: 1189
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount PCB, Screw
Mounting Type Chassis Mount
Package / Case Module
Number of Pins 28
Transistor Element Material SILICON
Technical
Operating Temperature -40°C~125°C
Published 2002
Series EconoPACK? 2
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Max Power Dissipation 210W
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 28
Qualification Status Not Qualified
Number of Elements 6
Configuration Full Bridge Inverter
Case Connection ISOLATED
Power - Max 210W
Halogen Free Not Halogen Free
Polarity/Channel Type N-CHANNEL
Input Standard
Collector Emitter Voltage (VCEO) 1.2kV
Max Collector Current 55A
Current - Collector Cutoff (Max) 5mA
Voltage - Collector Emitter Breakdown (Max) 1200V
Turn On Time 140 ns
Vce(on) (Max) @ Vge, Ic 2.15V @ 15V, 35A
Turn Off Time-Nom (toff) 610 ns
NTC Thermistor Yes
Input Capacitance (Cies) @ Vce 2.5nF @ 25V
Dimensions
Height 17mm
Length 107.5mm
Width 45mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
