FF300R07KE4HOSA1
RoHS
/
Package Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MODULE 650V 940W
PDF
/
Buying Options
Total Price: USD $99.58
Unit Price: USD $99.5808
≥1 USD $99.5808
≥10 USD $92.17648
≥100 USD $88.81253
≥500 USD $84.775574
Inventory: 31
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Chassis Mount
Package / Case Module
Surface Mount NO
Number of Pins 7
Transistor Element Material SILICON
Technical
Operating Temperature -40°C~150°C
Published 2002
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Additional Feature UL RECOGNIZED
Terminal Position UPPER
Terminal Form UNSPECIFIED
Pin Count 7
Number of Elements 2
Polarity NPN
Configuration 2 Independent
Element Configuration Dual
Case Connection ISOLATED
Power - Max 940W
Transistor Application POWER CONTROL
Halogen Free Not Halogen Free
Input Standard
Current - Collector Cutoff (Max) 5mA
Voltage - Collector Emitter Breakdown (Max) 650V
Turn On Time 143 ns
Vce(on) (Max) @ Vge, Ic 1.95V @ 15V, 300A
Turn Off Time-Nom (toff) 491 ns
IGBT Type Trench Field Stop
NTC Thermistor No
Input Capacitance (Cies) @ Vce 19nF @ 25V
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
