FF1500R12IE5BPSA1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MOD 1200V 1500A 20MW
PDF
/
Buying Options
Total Price: USD $864.27
Unit Price: USD $864.2744
≥1 USD $864.2744
Inventory: 982
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Chassis Mount
Package / Case Module
Technical
Operating Temperature -40°C~175°C TJ
Published 2002
Series PrimePACK?3+
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Configuration 2 Independent
Power - Max 20mW
Input Standard
Current - Collector Cutoff (Max) 5mA
Voltage - Collector Emitter Breakdown (Max) 1200V
Current - Collector (Ic) (Max) 1500A
Vce(on) (Max) @ Vge, Ic 2.15V @ 15V, 1500A
IGBT Type Trench Field Stop
NTC Thermistor Yes
Input Capacitance (Cies) @ Vce 82nF @ 25V
Compliance
RoHS Status ROHS3 Compliant
