FB30R06W1E3BOMA1
RoHS
/
Package Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MODULE 600V 39A 115W
PDF
/
Buying Options
Total Price: USD $35.19
Unit Price: USD $35.1912
≥1 USD $35.1912
≥10 USD $31.35807
≥100 USD $29.490454
≥500 USD $27.524385
≥1000 USD $26.541354
Inventory: 124
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Screw
Mounting Type Chassis Mount
Package / Case Module
Number of Pins 19
Transistor Element Material SILICON
Technical
Operating Temperature -40°C~150°C
Published 2002
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 23
ECCN Code EAR99
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 23
JESD-30 Code R-XUFM-X23
Qualification Status Not Qualified
Number of Elements 6
Configuration Three Phase Inverter
Power Dissipation 115W
Case Connection ISOLATED
Halogen Free Not Halogen Free
Polarity/Channel Type N-CHANNEL
Input Standard
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 39A
Current - Collector Cutoff (Max) 1mA
Current - Collector (Ic) (Max) 39A
Collector Emitter Saturation Voltage 2V
Turn On Time 42 ns
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 30A
Turn Off Time-Nom (toff) 245 ns
IGBT Type Trench Field Stop
NTC Thermistor Yes
Input Capacitance (Cies) @ Vce 1.65nF @ 25V
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
