BSM30GP60B2BOSA1

Infineon Technologies
RoHS
/
Package Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description IGBT MODULE 600V 50A 180W
PDF
/
Inventory: 3666
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Chassis Mount
Package / Case Module

Technical

Operating Temperature -40°C~125°C
Part Status Last Time Buy
Configuration Full Bridge
Power - Max 180W
Input Three Phase Bridge Rectifier
Current - Collector Cutoff (Max) 500μA
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 50A
Vce(on) (Max) @ Vge, Ic 2.45V @ 15V, 30A
NTC Thermistor Yes
Input Capacitance (Cies) @ Vce 1.6nF @ 25V
