BSM300GA120DN2HOSA1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MOD 1200V 430A 2500W
PDF
/
Buying Options
Total Price: USD $665.09
Unit Price: USD $665.091508
≥1 USD $665.091508
≥200 USD $265.376477
≥500 USD $256.50915
≥1000 USD $252.12669
Inventory: 10005
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Input Capacitance (Cies) @ Vce 22nF @ 25V
NTC Thermistor No
Turn Off Time-Nom (toff) 680 ns
Vce(on) (Max) @ Vge, Ic 3V @ 15V, 300A
Turn On Time 210 ns
Current - Collector (Ic) (Max) 430A
Voltage - Collector Emitter Breakdown (Max) 1200V
Current - Collector Cutoff (Max) 5.6mA
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application GENERAL PURPOSE SWITCHING
Power - Max 2500W
Case Connection ISOLATED
Configuration Single Switch
Number of Elements 1
JESD-30 Code R-XUFM-X4
Pin Count 4
Terminal Form UNSPECIFIED
Terminal Position UPPER
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case Module
Mounting Type Chassis Mount
Alternative Model
