FP40R12KE3
RoHS
/
Package /
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
INFINEON FP40R12KE3 IGBT Array & Module Transistor, N Channel, 55 A, 2.3 V, 200 W, 1.2 kV, EconoPIM
PDF
/
Buying Options
Total Price: USD $211.91
Unit Price: USD $211.906993
≥1 USD $211.906993
≥200 USD $82.005755
≥500 USD $82.005755
≥1000 USD $77.699622
Inventory: 5136
Minimum: 1
-
+
Technical Details
Physical
Surface Mount NO
Number of Terminals 24
Transistor Element Material SILICON
Technical
Pbfree Code icon-pbfree no
ECCN Code EAR99
Subcategory Insulated Gate BIP Transistors
Terminal Position UPPER
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 24
JESD-30 Code R-XUFM-W24
Qualification Status Not Qualified
Operating Temperature (Max) 175°C
Number of Elements 7
Configuration COMPLEX
Case Connection ISOLATED
Transistor Application POWER CONTROL
Polarity/Channel Type N-CHANNEL
Power Dissipation-Max (Abs) 200W
Turn On Time 140 ns
Collector Current-Max (IC) 55A
Turn Off Time-Nom (toff) 610 ns
Collector-Emitter Voltage-Max 1200V
Gate-Emitter Voltage-Max 20V
VCEsat-Max 2.3 V
Compliance
RoHS Status RoHS Compliant
