BSM75GB60DLC
RoHS
/
Package /
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT Modules 600V 75A DUAL
PDF
/
Inventory: 6028
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
VCEsat-Max 2.45 V
Gate-Emitter Voltage-Max 20V
Collector-Emitter Voltage-Max 600V
Turn Off Time-Nom (toff) 205 ns
Collector Current-Max (IC) 100A
Turn On Time 90 ns
Power Dissipation-Max (Abs) 355W
Polarity/Channel Type N-CHANNEL
Case Connection ISOLATED
Configuration SERIES, 2 ELEMENTS WITH BUILT-IN DIODE
Number of Elements 2
Operating Temperature (Max) 150°C
Qualification Status Not Qualified
JESD-30 Code R-XUFM-X7
Pin Count 7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Insulated Gate BIP Transistors
ECCN Code EAR99
Pbfree Code icon-pbfree no
Physical
Transistor Element Material SILICON
Number of Terminals 7
Surface Mount NO
