SI8405DB-T1-E1
RoHS
RoHS compliant
RoHS compliantPackage 4-XFBGA, CSPBGA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 12V 3.6A 2X2 4-MFP
PDF
/
Buying Options
Total Price: USD $4.15
Unit Price: USD $4.1477
≥1 USD $4.1477
≥10 USD $3.40385
≥100 USD $3.29745
≥500 USD $3.19105
≥1000 USD $3.08465
Inventory: 1125
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Rds On Max 55 mΩ
Drain to Source Resistance 55mOhm
Drain to Source Breakdown Voltage -12V
Gate to Source Voltage (Vgs) 8V
Continuous Drain Current (ID) 3.6A
Turn-Off Delay Time 120 ns
Fall Time (Typ) 32 ns
Vgs (Max) ±8V
Drive Voltage (Max Rds On,Min Rds On) 1.8V 4.5V
Drain to Source Voltage (Vdss) 12V
Rise Time 32ns
Gate Charge (Qg) (Max) @ Vgs 21nC @ 4.5V
Current - Continuous Drain (Id) @ 25°C 3.6A Ta
Vgs(th) (Max) @ Id 950mV @ 250μA
Rds On (Max) @ Id, Vgs 55mOhm @ 1A, 4.5V
FET Type P-Channel
Turn On Delay Time 16 ns
Power Dissipation 1.47W
Element Configuration Single
Power Dissipation-Max 1.47W Ta
Technology MOSFET (Metal Oxide)
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series TrenchFET?
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Supplier Device Package 4-Microfoot
Number of Pins 4
Package / Case 4-XFBGA, CSPBGA
Mounting Type Surface Mount
Mount Surface Mount
