IRF9610S
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 200V 1.8A D2PAK
PDF
/
Buying Options
Total Price: USD $1.4
Unit Price: USD $1.40315
≥1 USD $1.40315
≥10 USD $1.1514
≥100 USD $1.1153
≥500 USD $1.0792
≥1000 USD $1.0431
Inventory: 1160
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Supplier Device Package D2PAK
Weight 1.437803g
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2016
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC -200V
Technology MOSFET (Metal Oxide)
Current Rating -1.8A
Number of Channels 1
Power Dissipation-Max 3W Ta 20W Tc
Element Configuration Single
Power Dissipation 20W
Turn On Delay Time 8 ns
FET Type P-Channel
Rds On (Max) @ Id, Vgs 3Ohm @ 900mA, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 170pF @ 25V
Current - Continuous Drain (Id) @ 25°C 1.8A Tc
Gate Charge (Qg) (Max) @ Vgs 11nC @ 10V
Rise Time 15ns
Drain to Source Voltage (Vdss) 200V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 8 ns
Turn-Off Delay Time 10 ns
Continuous Drain Current (ID) 1.8A
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage -200V
Input Capacitance 170pF
Drain to Source Resistance 3Ohm
Rds On Max 3 Ω
Dimensions
Height 4.83mm
Length 10.67mm
Width 9.65mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
