XP261N7002TR-G
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
GENERAL-PURPOSE N-CHANNEL MOSFET
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.216292
≥1 USD $0.216292
≥10 USD $0.204052
≥100 USD $0.192498
≥500 USD $0.181604
≥1000 USD $0.171317
Inventory: 1123
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 60V
Gate Charge (Qg) (Max) @ Vgs 380pC @ 10V
Current - Continuous Drain (Id) @ 25°C 150mA Ta
Input Capacitance (Ciss) (Max) @ Vds 18pF @ 20V
Vgs(th) (Max) @ Id 2.1V @ 250μA
Rds On (Max) @ Id, Vgs 5 Ω @ 100mA, 10V
FET Type N-Channel
Power Dissipation-Max 400mW Ta
Technology MOSFET (Metal Oxide)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
