CSD25202W15T
RoHS
/
Package 9-UFBGA, DSBGA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
TEXAS INSTRUMENTS CSD25202W15TMOSFET Transistor, P Channel, -4 A, -20 V, 0.021 ohm, -4.5 V, -750 mV
PDF
/
Buying Options
Total Price: USD $1.08
Unit Price: USD $1.0824
≥1 USD $1.0824
≥10 USD $0.88352
≥100 USD $0.68684
Inventory: 1196
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 9-UFBGA, DSBGA
Number of Pins 9
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series NexFET?
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Technology MOSFET (Metal Oxide)
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CSD25202
Number of Elements 1
Number of Channels 1
Power Dissipation-Max 500mW Ta
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Turn On Delay Time 15 ns
FET Type P-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 26m Ω @ 2A, 4.5V
Vgs(th) (Max) @ Id 1.05V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 1010pF @ 10V
Current - Continuous Drain (Id) @ 25°C 4A Ta
Gate Charge (Qg) (Max) @ Vgs 7.5nC @ 4.5V
Rise Time 12 ns
Drain to Source Voltage (Vdss) 20V
Drive Voltage (Max Rds On,Min Rds On) 1.8V 4.5V
Fall Time (Typ) 28 ns
Turn-Off Delay Time 64 ns
Continuous Drain Current (ID) -4A
Threshold Voltage -750mV
Gate to Source Voltage (Vgs) -6V
Drain Current-Max (Abs) (ID) 4A
Drain-source On Resistance-Max 0.052Ohm
DS Breakdown Voltage-Min 20V
Feedback Cap-Max (Crss) 27 pF
Dimensions
Height 625μm
Length 1.75mm
Width 1.75mm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
