CSD19505KTT
RoHS
RoHS compliant
RoHS compliantPackage TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 80V 200A DDPAK-3
PDF
/
Buying Options
Total Price: USD $2.64
Unit Price: USD $2.64
≥1 USD $2.64
≥10 USD $2.22024
≥100 USD $1.796168
Inventory: 914
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 4.44mm
Width 8.41mm
Length 10.18mm
Height 4.83mm
Technical
Avalanche Energy Rating (Eas) 510 mJ
DS Breakdown Voltage-Min 80V
Pulsed Drain Current-Max (IDM) 400A
Threshold Voltage 2.6V
Continuous Drain Current (ID) 200A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 6V 10V
Drain to Source Voltage (Vdss) 80V
Gate Charge (Qg) (Max) @ Vgs 76nC @ 10V
Current - Continuous Drain (Id) @ 25°C 200A Ta
Input Capacitance (Ciss) (Max) @ Vds 7920pF @ 40V
Vgs(th) (Max) @ Id 3.2V @ 250μA
Rds On (Max) @ Id, Vgs 3.1m Ω @ 100A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 300W Tc
Number of Elements 1
Base Part Number CSD19505
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Additional Feature AVALANCHE RATED
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series NexFET?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 12 Weeks
