CSD19502Q5B
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerTDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 80V 100A 8SON
PDF
/
Buying Options
Total Price: USD $1.48
Unit Price: USD $1.47725
≥1 USD $1.47725
≥10 USD $1.2122
≥100 USD $1.1742
≥500 USD $1.1362
≥1000 USD $1.0982
Inventory: 165589
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 950μm
Width 6mm
Length 5mm
Technical
Feedback Cap-Max (Crss) 22 pF
Avalanche Energy Rating (Eas) 274 mJ
Pulsed Drain Current-Max (IDM) 400A
Drain to Source Breakdown Voltage 80V
Gate to Source Voltage (Vgs) 20V
Threshold Voltage 2.7V
Continuous Drain Current (ID) 100A
Turn-Off Delay Time 22 ns
Fall Time (Typ) 7 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 6V 10V
Rise Time 6 ns
Gate Charge (Qg) (Max) @ Vgs 62nC @ 10V
Current - Continuous Drain (Id) @ 25°C 100A Ta
Input Capacitance (Ciss) (Max) @ Vds 4870pF @ 40V
Vgs(th) (Max) @ Id 3.3V @ 250μA
Rds On (Max) @ Id, Vgs 4.1m Ω @ 19A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 8 ns
Case Connection DRAIN
Power Dissipation 3.2W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 3.1W Ta 195W Tc
Number of Channels 1
Number of Elements 1
Base Part Number CSD19502
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Additional Feature AVALANCHE RATED, LOGIC LEVEL COMPATIBLE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series NexFET?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 8
Package / Case 8-PowerTDFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
