CSD17506Q5A
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerTDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET 30V,NCh NexFET Pwr MOSFET
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
≥10 USD $1.1396
≥100 USD $0.886336
≥500 USD $0.751238
≥1000 USD $0.61197
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1mm
Width 6mm
Length 4.9mm
Height 1.1mm
Technical
Feedback Cap-Max (Crss) 65 pF
Nominal Vgs 1.3 V
Avalanche Energy Rating (Eas) 259 mJ
Drain to Source Breakdown Voltage 30V
Drain-source On Resistance-Max 0.0053Ohm
Drain Current-Max (Abs) (ID) 23A
Gate to Source Voltage (Vgs) 20V
Threshold Voltage 1.3V
Continuous Drain Current (ID) 100A
Turn-Off Delay Time 13 ns
Fall Time (Typ) 5.3 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Rise Time 13ns
Gate Charge (Qg) (Max) @ Vgs 11nC @ 4.5V
Current - Continuous Drain (Id) @ 25°C 100A Tc
Input Capacitance (Ciss) (Max) @ Vds 1650pF @ 15V
Vgs(th) (Max) @ Id 1.8V @ 250μA
Rds On (Max) @ Id, Vgs 4m Ω @ 20A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 7.5 ns
Case Connection DRAIN
Power Dissipation 3.2W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 3.2W Ta
Number of Elements 1
Pin Count 8
Base Part Number CSD17506
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Additional Feature AVALANCHE RATED
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series NexFET?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 8
Package / Case 8-PowerTDFN
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 12 Weeks
Alternative Model
