CSD16322Q5C
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerTDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 25V 97A 8SON
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.2848
≥1 USD $1.2848
≥10 USD $1.05336
≥100 USD $0.819368
Inventory: 188
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 4 weeks ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-PowerTDFN
Number of Pins 8
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series NexFET?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Additional Feature AVALANCHE RATED
Subcategory FET General Purpose Power
Technology MOSFET (Metal Oxide)
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CSD16322
Pin Count 8
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 3.1W Ta
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 3.1W
Case Connection DRAIN
Turn On Delay Time 6.1 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 5m Ω @ 20A, 8V
Vgs(th) (Max) @ Id 1.4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 1365pF @ 12.5V
Current - Continuous Drain (Id) @ 25°C 21A Ta 97A Tc
Gate Charge (Qg) (Max) @ Vgs 9.7nC @ 4.5V
Rise Time 10.7 ns
Drain to Source Voltage (Vdss) 25V
Drive Voltage (Max Rds On,Min Rds On) 3V 8V
Vgs (Max) +10V, -8V
Fall Time (Typ) 3.7 ns
Turn-Off Delay Time 12.3 ns
Continuous Drain Current (ID) 97A
Threshold Voltage 1.1V
Gate to Source Voltage (Vgs) 10V
Drain-source On Resistance-Max 0.007Ohm
DS Breakdown Voltage-Min 25V
Nominal Vgs 1.1 V
Dimensions
Height 1.05mm
Length 5mm
Width 6mm
Thickness 1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
