STW9NK70Z
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 700V 7.5A TO-247
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6916
≥1 USD $0.6916
≥10 USD $0.5681
≥100 USD $0.55005
≥500 USD $0.532
≥1000 USD $0.5149
Inventory: 39258
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Series SuperMESH?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 700V
Technology MOSFET (Metal Oxide)
Current Rating 7.5A
Base Part Number STW9N
Pin Count 3
Number of Elements 1
Power Dissipation-Max 156W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 156W
Turn On Delay Time 22 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 1.2 Ω @ 4A, 10V
Vgs(th) (Max) @ Id 4.5V @ 100μA
Input Capacitance (Ciss) (Max) @ Vds 1370pF @ 25V
Current - Continuous Drain (Id) @ 25°C 7.5A Tc
Gate Charge (Qg) (Max) @ Vgs 68nC @ 10V
Rise Time 17ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Fall Time (Typ) 13 ns
Turn-Off Delay Time 45 ns
Continuous Drain Current (ID) 7.5A
Threshold Voltage 3.75V
Gate to Source Voltage (Vgs) 30V
Drain to Source Breakdown Voltage 700V
Dimensions
Height 5.3mm
Length 15.9mm
Width 20.3mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
