STW50NB20
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 200V 50A TO-247
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6112
≥1 USD $1.6112
≥10 USD $1.3224
≥100 USD $1.2806
≥500 USD $1.23975
≥1000 USD $1.19795
Inventory: 1364
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Series PowerMESH?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 200V
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 50A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STW50N
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 280W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 280W
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 55m Ω @ 25A, 10V
Vgs(th) (Max) @ Id 5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 3400pF @ 25V
Current - Continuous Drain (Id) @ 25°C 50A Tc
Gate Charge (Qg) (Max) @ Vgs 115nC @ 10V
Rise Time 65 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Fall Time (Typ) 27 ns
Continuous Drain Current (ID) 50A
Gate to Source Voltage (Vgs) 30V
Drain-source On Resistance-Max 0.055Ohm
Drain to Source Breakdown Voltage 200V
Pulsed Drain Current-Max (IDM) 200A
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
