STW48N60M2-4
RoHS
RoHS compliant
RoHS compliantPackage TO-247-4
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 600V 42A TO247-4
PDF
/
Buying Options
Total Price: USD $6.92
Unit Price: USD $6.9168
≥1 USD $6.9168
≥10 USD $5.522
≥100 USD $4.94083
≥500 USD $4.359573
≥1000 USD $3.923612
≥3000 USD $3.67657
Inventory: 342
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Continuous Drain Current (ID) 42A
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 600V
Gate Charge (Qg) (Max) @ Vgs 70nC @ 10V
Current - Continuous Drain (Id) @ 25°C 42A Tc
Input Capacitance (Ciss) (Max) @ Vds 3060pF @ 100V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 70m Ω @ 21A, 10V
FET Type N-Channel
Power Dissipation-Max 300W Tc
Configuration Single
Base Part Number STW48N
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MDmesh? M2
Packaging Tube
Operating Temperature 150°C TJ
Physical
Package / Case TO-247-4
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 26 Weeks
