STW45NM50FD
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 500V 45A 3-Pin(3+Tab) TO-247 Tube
PDF
/
Buying Options
Total Price: USD $1.18
Unit Price: USD $1.177578
≥1 USD $1.177578
≥10 USD $1.110929
≥100 USD $1.048048
≥500 USD $0.988716
≥1000 USD $0.932755
Inventory: 1160
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 5.15mm
Length 15.75mm
Height 20.15mm
Technical
Drain to Source Breakdown Voltage 500V
Gate to Source Voltage (Vgs) 30V
Threshold Voltage 4V
Continuous Drain Current (ID) 45A
Turn-Off Delay Time 21.6 ns
Fall Time (Typ) 87.7 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 107.5ns
Gate Charge (Qg) (Max) @ Vgs 120nC @ 10V
Current - Continuous Drain (Id) @ 25°C 45A Tc
Input Capacitance (Ciss) (Max) @ Vds 3600pF @ 25V
Vgs(th) (Max) @ Id 5V @ 250μA
Rds On (Max) @ Id, Vgs 100m Ω @ 22.5A, 10V
FET Type N-Channel
Turn On Delay Time 26.5 ns
Power Dissipation 417W
Element Configuration Single
Power Dissipation-Max 417W Tc
Number of Elements 1
Pin Count 3
Base Part Number STW45N
Current Rating 45A
Reach Compliance Code not_compliant
Technology MOSFET (Metal Oxide)
Voltage - Rated DC 500V
Resistance 100mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series FDmesh?
Packaging Tube
Operating Temperature -65°C~150°C TJ
Physical
Weight 9.071847g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
