STW40N95DK5
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CHANNEL 950V 38A TO247
PDF
/
Buying Options
Total Price: USD $53.7
Unit Price: USD $53.6959
≥1 USD $53.6959
≥10 USD $44.05815
≥100 USD $42.6816
≥500 USD $41.30505
≥1000 USD $39.92755
Inventory: 1176
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mounting Type Through Hole
Package / Case TO-247-3
Technical
Operating Temperature -55°C~150°C
Packaging Tube
Series MDmesh? DK5
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Base Part Number STW40N
Power Dissipation-Max 450W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 130m Ω @ 19A, 10V
Vgs(th) (Max) @ Id 5V @ 100μA
Input Capacitance (Ciss) (Max) @ Vds 3480pF @ 100V
Current - Continuous Drain (Id) @ 25°C 38A Tc
Gate Charge (Qg) (Max) @ Vgs 100nC @ 10V
Drain to Source Voltage (Vdss) 950V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Compliance
RoHS Status ROHS3 Compliant
