STW30NM60N
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-channel 600V, 25A Power II Mdmesh
PDF
/
Buying Options
Total Price: USD $2.65
Unit Price: USD $2.6543
≥1 USD $2.6543
≥10 USD $2.1774
≥100 USD $2.10995
≥500 USD $2.04155
≥1000 USD $1.97315
Inventory: 1722
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Series MDmesh? II
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Resistance 130mOhm
Terminal Finish TIN
Subcategory FET General Purpose Power
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STW30N
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 190W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 190W
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 130m Ω @ 12.5A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 2700pF @ 50V
Current - Continuous Drain (Id) @ 25°C 25A Tc
Gate Charge (Qg) (Max) @ Vgs 91nC @ 10V
Rise Time 24ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Fall Time (Typ) 70 ns
Turn-Off Delay Time 125 ns
Continuous Drain Current (ID) 25A
JEDEC-95 Code TO-247AC
Gate to Source Voltage (Vgs) 30V
Drain to Source Breakdown Voltage 600V
Avalanche Energy Rating (Eas) 900 mJ
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
