STW26NM60ND
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 600V 21A TO247
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.608697
≥1 USD $1.608697
≥10 USD $1.517629
≥100 USD $1.431739
≥500 USD $1.350692
≥1000 USD $1.274241
Inventory: 1169
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5.15mm
Length 15.75mm
Height 20.15mm
Technical
Pulsed Drain Current-Max (IDM) 84A
Drain to Source Breakdown Voltage 600V
Gate to Source Voltage (Vgs) 25V
Continuous Drain Current (ID) 21A
Turn-Off Delay Time 69 ns
Fall Time (Typ) 27.5 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 14.5ns
Gate Charge (Qg) (Max) @ Vgs 54.6nC @ 10V
Current - Continuous Drain (Id) @ 25°C 21A Tc
Input Capacitance (Ciss) (Max) @ Vds 1817pF @ 100V
Vgs(th) (Max) @ Id 5V @ 250μA
Rds On (Max) @ Id, Vgs 175m Ω @ 10.5A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 22 ns
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 190W Tc
Number of Channels 1
Number of Elements 1
Base Part Number STW26N
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series FDmesh? II
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Weight 38.000013g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
