STW26N60M2
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 600V 20A TO247
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.7544
≥1 USD $2.7544
≥10 USD $2.30912
≥100 USD $1.868152
≥500 USD $1.66056
≥1000 USD $1.42186
≥3000 USD $1.338832
Inventory: 617
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mounting Type Through Hole
Package / Case TO-247-3
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Series MDmesh? M2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Base Part Number STW26N
Power Dissipation-Max 169W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 165m Ω @ 10A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 1360pF @ 100V
Current - Continuous Drain (Id) @ 25°C 20A Tc
Gate Charge (Qg) (Max) @ Vgs 34nC @ 10V
Drain to Source Voltage (Vdss) 600V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Compliance
RoHS Status ROHS3 Compliant
