STW20NB50
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 500V 20A TO-247
PDF
/
Buying Options
Total Price: USD $3.45
Unit Price: USD $3.4466
≥1 USD $3.4466
≥10 USD $2.82815
≥100 USD $2.7398
≥500 USD $2.65145
≥1000 USD $2.5631
Inventory: 1547
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Turn On Time-Max (ton) 57 ns
Feedback Cap-Max (Crss) 75 pF
Avalanche Energy Rating (Eas) 1000 mJ
Pulsed Drain Current-Max (IDM) 80A
Drain to Source Breakdown Voltage 500V
Drain-source On Resistance-Max 0.25Ohm
Gate to Source Voltage (Vgs) 30V
JEDEC-95 Code TO-247AC
Continuous Drain Current (ID) 20A
Fall Time (Typ) 25 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 15 ns
Gate Charge (Qg) (Max) @ Vgs 110nC @ 10V
Current - Continuous Drain (Id) @ 25°C 20A Tc
Input Capacitance (Ciss) (Max) @ Vds 4700pF @ 25V
Vgs(th) (Max) @ Id 5V @ 250μA
Rds On (Max) @ Id, Vgs 250m Ω @ 10A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Power Dissipation 250W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 250W Tc
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number STW20N
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 20A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Voltage - Rated DC 500V
Subcategory FET General Purpose Power
HTS Code 8541.29.00.95
Additional Feature AVALANCHE RATED
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series PowerMESH?
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
