STU16N65M2
RoHS
RoHS compliant
RoHS compliantPackage TO-251-3 Short Leads, IPak, TO-251AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 650V 11A IPAK
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
≥10 USD $1.598784
≥100 USD $1.315486
≥500 USD $1.113094
≥1000 USD $0.944442
≥3000 USD $0.897222
Inventory: 10587
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-251-3 Short Leads, IPak, TO-251AA
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Series MDmesh? M2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STU16N
Power Dissipation-Max 110W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 360m Ω @ 5.5A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 718pF @ 100V
Current - Continuous Drain (Id) @ 25°C 11A Tc
Gate Charge (Qg) (Max) @ Vgs 19.5nC @ 10V
Drain to Source Voltage (Vdss) 650V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Continuous Drain Current (ID) 11A
Compliance
RoHS Status ROHS3 Compliant
