STS4DPFS30L
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-Ch 30 Volt 5 Amp
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 18
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Technical
FET Feature Schottky Diode (Isolated)
Drain to Source Breakdown Voltage -30V
Drain-source On Resistance-Max 0.095Ohm
Drain Current-Max (Abs) (ID) 4A
Gate to Source Voltage (Vgs) 16V
Continuous Drain Current (ID) 5A
Turn-Off Delay Time 125 ns
Fall Time (Typ) 35 ns
Vgs (Max) ±16V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 30V
Rise Time 35ns
Gate Charge (Qg) (Max) @ Vgs 16nC @ 5V
Current - Continuous Drain (Id) @ 25°C 5A Tc
Input Capacitance (Ciss) (Max) @ Vds 1350pF @ 25V
Vgs(th) (Max) @ Id 2.5V @ 250μA
Rds On (Max) @ Id, Vgs 55m Ω @ 2.5A, 10V
Transistor Application SWITCHING
FET Type P-Channel
Turn On Delay Time 25 ns
Power Dissipation 2.5W
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 2.5W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 8
Base Part Number STS4D
Time@Peak Reflow Temperature-Max (s) 30
Current Rating -5A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Voltage - Rated DC -30V
Subcategory Other Transistors
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series STripFET?
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
