STS10P4LLF6
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 40V 10A 8SOIC
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4256
≥1 USD $1.4256
≥10 USD $1.16336
≥100 USD $0.90464
≥500 USD $0.766832
≥1000 USD $0.624659
Inventory: 1174
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature 150┬?C TJ
Packaging Cut Tape (CT)
Series STripFETō?ó F6
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Subcategory Other Transistors
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STS10
Power Dissipation-Max 2.7W Ta
Element Configuration Single
Turn On Delay Time 49.4 ns
FET Type P-Channel
Rds On (Max) @ Id, Vgs 15m ╬? @ 3A, 10V
Vgs(th) (Max) @ Id 1V @ 250╬╝A (Min)
Input Capacitance (Ciss) (Max) @ Vds 3525pF @ 25V
Current - Continuous Drain (Id) @ 25┬?C 10A Ta
Gate Charge (Qg) (Max) @ Vgs 34nC @ 4.5V
Drain to Source Voltage (Vdss) 40V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Vgs (Max) ┬?20V
Turn-Off Delay Time 170 ns
Continuous Drain Current (ID) 10A
Gate to Source Voltage (Vgs) 20V
Dimensions
Height 1.5mm
Length 5mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
