STP95N04
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 40V 80A TO-220
PDF
/
Inventory: 9991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Avalanche Energy Rating (Eas) 400 mJ
Pulsed Drain Current-Max (IDM) 320A
Drain to Source Breakdown Voltage 40V
Drain-source On Resistance-Max 0.0065Ohm
Gate to Source Voltage (Vgs) 20V
JEDEC-95 Code TO-220AB
Continuous Drain Current (ID) 80A
Turn-Off Delay Time 40 ns
Fall Time (Typ) 15 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 50ns
Gate Charge (Qg) (Max) @ Vgs 54nC @ 10V
Current - Continuous Drain (Id) @ 25°C 80A Tc
Input Capacitance (Ciss) (Max) @ Vds 2200pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 6.5m Ω @ 40A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 15 ns
Case Connection DRAIN
Power Dissipation 110W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 110W Tc
Number of Elements 1
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number STP95
Current Rating 80A
Technology MOSFET (Metal Oxide)
Voltage - Rated DC 40V
Subcategory FET General Purpose Power
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series STripFET?
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
