STP85N3LH5
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 30V 80A 3-Pin(3+Tab) TO-220 Tube
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 391
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Drain to Source Breakdown Voltage 30V
Gate to Source Voltage (Vgs) 22V
JEDEC-95 Code TO-220AB
Threshold Voltage 2.5V
Continuous Drain Current (ID) 80A
Turn-Off Delay Time 23.6 ns
Fall Time (Typ) 10.8 ns
Vgs (Max) ±22V
Drive Voltage (Max Rds On,Min Rds On) 5V 10V
Rise Time 14 ns
Gate Charge (Qg) (Max) @ Vgs 14nC @ 5V
Current - Continuous Drain (Id) @ 25°C 80A Tc
Input Capacitance (Ciss) (Max) @ Vds 1850pF @ 25V
Vgs(th) (Max) @ Id 2.5V @ 250μA
Rds On (Max) @ Id, Vgs 5.4m Ω @ 40A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 6 ns
Case Connection DRAIN
Power Dissipation 70W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 70W Tc
Number of Elements 1
Pin Count 3
Base Part Number STP85N
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Additional Feature ULTRA-LOW RESISTANCE
Terminal Finish Matte Tin (Sn)
Resistance 5mOhm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series STripFET? V
Packaging Tube
Operating Temperature 175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 14 Weeks
