STP80NF03L-04
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 30V 80A TO-220
PDF
/
Buying Options
Total Price: USD $1.51
Unit Price: USD $1.51497
≥1 USD $1.51497
≥10 USD $1.42922
≥100 USD $1.34832
≥500 USD $1.272
≥1000 USD $1.2
≥3000 USD $1.13208
Inventory: 3317
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 175°C TJ
Packaging Tube
Series STripFET? II
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 4.5MOhm
Terminal Finish Matte Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 30V
Technology MOSFET (Metal Oxide)
Current Rating 80A
Base Part Number STP80N
Pin Count 3
Number of Elements 1
Number of Channels 1
Power Dissipation-Max 300W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 300W
Case Connection DRAIN
Turn On Delay Time 30 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 4.5m Ω @ 40A, 10V
Vgs(th) (Max) @ Id 2.5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 5500pF @ 25V
Current - Continuous Drain (Id) @ 25°C 80A Tc
Gate Charge (Qg) (Max) @ Vgs 110nC @ 4.5V
Rise Time 270ns
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Vgs (Max) ±20V
Fall Time (Typ) 95 ns
Turn-Off Delay Time 110 ns
Continuous Drain Current (ID) 80A
Threshold Voltage 1.5V
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage 30V
Max Junction Temperature (Tj) 175°C
Dimensions
Height 19.68mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
