STP77N6F6
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-Ch 60V 6.6mOhm 77A STripFET VI
PDF
/
Buying Options
Total Price: USD $1.35
Unit Price: USD $1.3464
≥1 USD $1.3464
≥10 USD $1.083456
≥100 USD $0.858616
≥500 USD $0.727742
≥1000 USD $0.59283
Inventory: 1144
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Drain to Source Breakdown Voltage 60V
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 77A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Gate Charge (Qg) (Max) @ Vgs 76nC @ 10V
Current - Continuous Drain (Id) @ 25°C 77A Tc
Input Capacitance (Ciss) (Max) @ Vds 5300pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 7m Ω @ 38.5A, 10V
FET Type N-Channel
Power Dissipation 80W
Power Dissipation-Max 80W Tc
Configuration Single
Number of Elements 1
Base Part Number STP77N
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Powers
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series DeepGATE?, STripFET? VI
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
