STP6N62K3
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 620V 5.5A TO-220
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.6456
≥1 USD $1.6456
≥10 USD $1.325456
≥100 USD $1.090496
≥500 USD $0.922733
≥1000 USD $0.782927
≥3000 USD $0.743785
Inventory: 139
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Series SuperMESH3?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 1.2Ohm
Terminal Finish Matte Tin (Sn)
Additional Feature ULTRA LOW-ON RESISTANCE
Subcategory FET General Purpose Power
Technology MOSFET (Metal Oxide)
Base Part Number STP6N
Pin Count 3
Number of Elements 1
Power Dissipation-Max 90W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 90W
Turn On Delay Time 22 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 1.2 Ω @ 2.8A, 10V
Vgs(th) (Max) @ Id 4.5V @ 50μA
Input Capacitance (Ciss) (Max) @ Vds 875pF @ 50V
Current - Continuous Drain (Id) @ 25°C 5.5A Tc
Gate Charge (Qg) (Max) @ Vgs 34nC @ 10V
Rise Time 12.5ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Fall Time (Typ) 19 ns
Turn-Off Delay Time 49 ns
Continuous Drain Current (ID) 5.5A
Threshold Voltage 3.75V
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 30V
Drain to Source Breakdown Voltage 620V
Pulsed Drain Current-Max (IDM) 22A
Dimensions
Height 15.75mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
