STP5NK80ZFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 800V 4.3A 3-Pin(3+Tab) TO-220FP Tube
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.2088
≥1 USD $2.2088
≥10 USD $1.777072
≥100 USD $1.46212
≥500 USD $1.237157
≥1000 USD $1.049708
≥3000 USD $0.997225
Inventory: 972
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.3mm
Technical
Drain to Source Breakdown Voltage 800V
Gate to Source Voltage (Vgs) 30V
Threshold Voltage 3.75V
Continuous Drain Current (ID) 4.3A
Turn-Off Delay Time 45 ns
Fall Time (Typ) 30 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 25 ns
Gate Charge (Qg) (Max) @ Vgs 45.5nC @ 10V
Current - Continuous Drain (Id) @ 25°C 4.3A Tc
Input Capacitance (Ciss) (Max) @ Vds 910pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 100μA
Rds On (Max) @ Id, Vgs 2.4 Ω @ 2.15A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 18 ns
Case Connection ISOLATED
Power Dissipation 30W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 30W Tc
Number of Elements 1
Pin Count 3
Base Part Number STP5N
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Terminal Finish Matte Tin (Sn) - annealed
Resistance 2.4Ohm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PowerMESH?
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
