STP4NK60ZFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 600V 4A TO-220FP
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.1352
≥1 USD $1.1352
≥10 USD $0.908688
≥100 USD $0.74756
≥500 USD $0.67496
Inventory: 6965
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.3mm
Technical
Nominal Vgs 3.75 V
Dual Supply Voltage 600V
Drain to Source Breakdown Voltage 600V
Drain Current-Max (Abs) (ID) 4A
Gate to Source Voltage (Vgs) 30V
JEDEC-95 Code TO-220AB
Threshold Voltage 3.75V
Continuous Drain Current (ID) 4A
Turn-Off Delay Time 29 ns
Fall Time (Typ) 16.5 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 9.5 ns
Gate Charge (Qg) (Max) @ Vgs 26nC @ 10V
Current - Continuous Drain (Id) @ 25°C 4A Tc
Input Capacitance (Ciss) (Max) @ Vds 510pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 50μA
Rds On (Max) @ Id, Vgs 2 Ω @ 2A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 12 ns
Case Connection ISOLATED
Power Dissipation 25W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 25W Tc
Number of Elements 1
Pin Count 3
Base Part Number STP4N
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Resistance 2Ohm
ECCN Code EAR99
Termination Through Hole
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SuperMESH?
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 12 Weeks
