STP4NK50ZD
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 500V 3A 3-Pin(3+Tab) TO-220 Tube
PDF
/
Buying Options
Total Price: USD $8.32
Unit Price: USD $8.3239
≥1 USD $8.3239
≥10 USD $6.82955
≥100 USD $6.61675
≥500 USD $6.403
≥1000 USD $6.18925
Inventory: 1470
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 8 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Series SuperMESH?
JESD-609 Code e3
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 500V
Technology MOSFET (Metal Oxide)
Current Rating 3A
Base Part Number STP4N
Pin Count 3
Number of Elements 1
Power Dissipation-Max 45W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 45W
Turn On Delay Time 9.5 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 2.7 Ω @ 1.5A, 10V
Vgs(th) (Max) @ Id 4.5V @ 50μA
Input Capacitance (Ciss) (Max) @ Vds 310pF @ 25V
Current - Continuous Drain (Id) @ 25°C 3A Tc
Gate Charge (Qg) (Max) @ Vgs 12nC @ 10V
Rise Time 15.5 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Fall Time (Typ) 22 ns
Turn-Off Delay Time 23 ns
Continuous Drain Current (ID) 3A
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 30V
Drain Current-Max (Abs) (ID) 3A
Drain to Source Breakdown Voltage 500V
Dimensions
Height 15.75mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
