STP25NM50N
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CHANNEL MOSFET Power MDmesh
PDF
/
Buying Options
Total Price: USD $4.88
Unit Price: USD $4.8792
≥1 USD $4.8792
≥10 USD $4.0033
≥100 USD $3.8779
≥500 USD $3.75345
≥1000 USD $3.62805
Inventory: 1485
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Series MDmesh?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 140mOhm
Terminal Finish Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 550V
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 22A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STP25N
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 160W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 160W
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 140m Ω @ 11A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 2565pF @ 25V
Current - Continuous Drain (Id) @ 25°C 22A Tc
Gate Charge (Qg) (Max) @ Vgs 84nC @ 10V
Rise Time 23ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Fall Time (Typ) 22 ns
Turn-Off Delay Time 75 ns
Continuous Drain Current (ID) 22A
Threshold Voltage 3V
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 25V
Drain to Source Breakdown Voltage 500V
Pulsed Drain Current-Max (IDM) 88A
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
