STP16NK65Z
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N Ch 650 V 0.38 Ohm 13A
PDF
/
Inventory: 3816
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Avalanche Energy Rating (Eas) 350 mJ
Pulsed Drain Current-Max (IDM) 52A
Drain to Source Breakdown Voltage 650V
Drain-source On Resistance-Max 0.5Ohm
Gate to Source Voltage (Vgs) 30V
JEDEC-95 Code TO-220AB
Continuous Drain Current (ID) 13A
Turn-Off Delay Time 68 ns
Fall Time (Typ) 17 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 25ns
Gate Charge (Qg) (Max) @ Vgs 89nC @ 10V
Current - Continuous Drain (Id) @ 25°C 13A Tc
Input Capacitance (Ciss) (Max) @ Vds 2750pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 100μA
Rds On (Max) @ Id, Vgs 500m Ω @ 6.5A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 25 ns
Power Dissipation 190W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 190W Tc
Number of Elements 1
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number STP16N
Current Rating 13A
Technology MOSFET (Metal Oxide)
Voltage - Rated DC 650V
Subcategory FET General Purpose Power
Additional Feature AVALANCHE RATED
Terminal Finish Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series SuperMESH?
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
